CCD Detector
Digital Radiography CCD Brochure

Detector Type

16 Mega Pixel KODAK Extreme KAF Series CCD Detector Chip.

Optical Specification

Exclusive Leading Edge Optical Array with Breakthrough Light Transfer and Distortion Elimination Capability Using NO Mirrors.


4096 x 4096 pixels Overall Imaging Resolution. Minimum 4.6 Line Pair per mm Resolution.

Acquisition Time

Approximately 3 to 5 Seconds From Exposure to Displayed Image.

Recycle Time

Zero Time Lag Between Subsequent Image Acquisitions.

Scintillation Screen

Scintillation Screen (Cesium Iodide)

Active Image Area

43 x 43 cm Active Area.

DICOM Format

Full DICOM 3.0 “Push/Pull” Connectivity to HIS/RIS and Practice Management Systems. Easy to Burn CD with on Board Auto Launching Mini Viewer

Unique / Exclusive Features
  • Highly Advanced and Exclusive “Dark Current” Compensation Algorithm
  • Complex and Effective Anatomical Filter Sets (Libraries)
  • Compact Design for More Efficient Integration with Mechanical Assemblies
  • Such as “U” Arms, Tables, Chest (Wall) Stands, etc.
  • Elimination of All Moving Parts; There are NO Fans, NO Cooling Pumps, and NO Chips
Workstation Specifications
  • Leading edge Intel CPU min.
  • 4 GB High Speed RAM min.
  • 1 TB Hard Disk Drive @ 7200 RPM min.
  • Indepenent PCI Video Graphics Card (1 GB) min and Dedicated Image
  • Processing Electronics.
  • DVD/CD Drive @ 16 RW with Burner.
  • Windows 7 Operating System.
Monitor Specifications
  • 2 MB High Contrast 1920 x 1080.
  • Minimum 21.5 inch.
  • Touch Screen (Optional)
